316L body, full port, ISO 5211 pad, hydro-tested at 1.5× with certificate per batch
Part no.: NV-VLV-2050
| Body material | CF8M / AISI 316L |
|---|---|
| Nominal size | DN50 (2") |
| Pressure rating | PN40 |
| Port | Full port |
| Seat material | Reinforced PTFE (RTFE) |
| End connection | Threaded BSP / NPT, or butt-weld on request |
| Temperature range | −20 °C to +180 °C |
| Actuator mounting | ISO 5211 F07/F10 square 17 mm |
| Shell test | 1.5 × rating (6.0 MPa), 100% of valves |
| Seat test | 1.1 × rating (4.4 MPa), zero leakage |
| Weight | 2.35 kg |
A two-piece full-port ball valve in CF8M (316L) with a reinforced PTFE seat, rated PN40 and suitable for steam, water, gas and mildly aggressive media. The ISO 5211 mounting pad takes a direct-mount pneumatic or electric actuator without an adapter bracket.
Every valve is shell-tested at 1.5× the pressure rating and seat-tested at 1.1× before packing. Certificates are issued per batch and reference the heat number of the body casting, so a material question can be answered years later.
Steam distribution in food plants, CIP lines in dairies, compressed air isolation, and cooling-water manifolds on machine tools.
Individually. Shell and seat testing is applied to 100% of valves, not a sample. The certificate lists the test pressures and the batch reference, and can be traced to the body casting heat number.
Yes. We can supply the valve with a pneumatic double-acting or spring-return actuator mounted, tested and cycle-run before packing, so it arrives ready to pipe.
Yes, up to +180 °C with the standard RTFE seat. For saturated steam above 180 °C, specify the metal-seated variant — tell us the pressure and temperature and we will confirm the right seat material.
A pressure test certificate per batch, an EN 10204 3.1 material certificate for the body, and a packing list. A PED declaration of conformity and a material traceability chart are available on request at no extra cost.
Send drawings, a part number or a description of the component you need. We reply with a quotation, lead time and tooling assessment — usually within one business day.
