1.5 mm S355 sheet, IP54 gasket groove, RAL 7035, 500-hour salt spray
Part no.: NV-SHM-3110
| Material | S355MC cold-rolled sheet, 1.5 mm |
|---|---|
| External dimensions | 400 × 300 × 150 mm (customisable) |
| Protection class | IP54 with fitted gasket |
| Sheet thickness tolerance | ± 0.07 mm |
| Bend angle tolerance | ± 0.5° |
| Cut edge quality | Laser cut, deburred, Ra ≤ 6.3 µm |
| Finish | Zinc phosphate + powder coat RAL 7035, 70–80 µm |
| Corrosion resistance | 500 h neutral salt spray, no blistering |
| Weight | 2.9 kg |
A welded and powder-coated enclosure for machine-mounted control panels, produced from 1.5 mm S355 sheet with a formed gasket groove that takes a standard extruded seal to IP54. Hinges, locks and cable glands can be fitted before coating.
All flat patterns are nesting-optimised before cutting, which usually reduces material cost by 8–12% against a naive layout. The gasket groove is formed in a single press operation, so it stays concentric with the door through the whole batch.
Degreased, zinc phosphated and powder coated to RAL 7035 at 70–80 µm, tested to 500 hours neutral salt spray with no blistering.
Yes, as a DXF, once the design is agreed. Some customers cut the flat parts locally and buy only the formed and coated assemblies from us — that works fine and we quote it that way.
The groove is formed in a dedicated press tool that locates from the same reference edge as the door cut-out, and one assembly per batch is tested to IP54 with a water spray.
Yes, in 304 or 316L at 1.5 or 2.0 mm, without powder coating (brushed or glass-bead blasted finish). Expect roughly 2.6× the carbon steel price because of material and slower cutting.
Send drawings, a part number or a description of the component you need. We reply with a quotation, lead time and tooling assessment — usually within one business day.
